| Menge: | |
|---|---|
|
|
| Lager-Nr. | Abmessungen mm. | Laden von KN. | Gewicht | ||||||||
| d | D | B | C | Dk | R1s. | R2s. | α | dyna | stat. | kg | |
| Mindest | Mindest | ≈ | C | C0. | |||||||
| GE4C. | 4 | 12 | 5 | 3 | 8 | 0.3 | 0.3 | 16 | 2.1 | 5.4 | 0.003 |
| GE5C. | 5 | 14 | 6 | 4 | 10 | 0.3 | 0.3 | 13 | 3.6 | 9.1 | 0.005 |
| GE6C. | 6 | 14 | 6 | 4 | 10 | 0.3 | 0.3 | 13 | 3.6 | 9.1 | 0.004 |
| GE8C. | 8 | 16 | 8 | 5 | 13 | 0.3 | 0.3 | 15 | 5.8 | 14 | 0.008 |
| GE10C. | 10 | 19 | 9 | 6 | 16 | 0.3 | 0.3 | 12 | 8.6 | 21 | 0.011 |
| GE12C. | 12 | 22 | 10 | 7 | 18 | 0.3 | 0.3 | 10 | 11 | 28 | 0.015 |
| GE15C. | 15 | 26 | 12 | 9 | 22 | 0.3 | 0.3 | 8 | 18 | 45 | 0.027 |
| GE17C. | 17 | 30 | 14 | 10 | 25 | 0.3 | 0.3 | 10 | 22 | 56 | 0.041 |
| GE20C. | 20 | 35 | 16 | 12 | 29 | 0.3 | 0.3 | 9 | 31 | 78 | 0.066 |
| GE25C. | 25 | 42 | 20 | 16 | 35.5 | 0.6 | 0.6 | 7 | 51 | 127 | 0.119 |
| GE30C. | 30 | 47 | 22 | 18 | 40.7 | 0.6 | 0.6 | 6 | 65 | 166 | 0.163 |
-Outer Ring mit PTFE-Verbundmaterial ausgekleidet.
-Sphere Oberfläche des inneren Rings verchromt.
-Outer Ring ordnungsgemäß phosphat behandelt.
|
|
| Lager-Nr. | Abmessungen mm. | Laden von KN. | Gewicht | ||||||||
| d | D | B | C | Dk | R1s. | R2s. | α | dyna | stat. | kg | |
| Mindest | Mindest | ≈ | C | C0. | |||||||
| GE4C. | 4 | 12 | 5 | 3 | 8 | 0.3 | 0.3 | 16 | 2.1 | 5.4 | 0.003 |
| GE5C. | 5 | 14 | 6 | 4 | 10 | 0.3 | 0.3 | 13 | 3.6 | 9.1 | 0.005 |
| GE6C. | 6 | 14 | 6 | 4 | 10 | 0.3 | 0.3 | 13 | 3.6 | 9.1 | 0.004 |
| GE8C. | 8 | 16 | 8 | 5 | 13 | 0.3 | 0.3 | 15 | 5.8 | 14 | 0.008 |
| GE10C. | 10 | 19 | 9 | 6 | 16 | 0.3 | 0.3 | 12 | 8.6 | 21 | 0.011 |
| GE12C. | 12 | 22 | 10 | 7 | 18 | 0.3 | 0.3 | 10 | 11 | 28 | 0.015 |
| GE15C. | 15 | 26 | 12 | 9 | 22 | 0.3 | 0.3 | 8 | 18 | 45 | 0.027 |
| GE17C. | 17 | 30 | 14 | 10 | 25 | 0.3 | 0.3 | 10 | 22 | 56 | 0.041 |
| GE20C. | 20 | 35 | 16 | 12 | 29 | 0.3 | 0.3 | 9 | 31 | 78 | 0.066 |
| GE25C. | 25 | 42 | 20 | 16 | 35.5 | 0.6 | 0.6 | 7 | 51 | 127 | 0.119 |
| GE30C. | 30 | 47 | 22 | 18 | 40.7 | 0.6 | 0.6 | 6 | 65 | 166 | 0.163 |
-Outer Ring mit PTFE-Verbundmaterial ausgekleidet.
-Sphere Oberfläche des inneren Rings verchromt.
-Outer Ring ordnungsgemäß phosphat behandelt.
